Description
Model XW40L, format 38x185mm, is microprocessor based controller, suitable for applications on
medium or low temperature refrigerating units. It has 3 relay outputs to control compressor, defrost,
which can be either electrical or reverse cycle (hot gas) and light (configurable). It could be provided
with a Real Time Clock which allows programming of up to 6 daily defrost cycles, divided into
holidays and workdays. A “Day and Night” function with two different set points is fitted for energy
saving. It is also provided with up to four NTC or PTC probe inputs, the first one for temperature
control, the second one, to be located onto the evaporator and to control the defrost termination
temperature. One of the 2 digital inputs can operate as third temperature probe. The fourth probe is
used to signal the condenser temperature alarm or to display a temperature.
